Glassware Washer ADGW-501

Glassware Washer ADGW-501

Glassware Washer ADGW-501 has a chamber with a capacity of 158 L. It features stainless steel washing cavity with dual-level racks, supporting diverse glassware. Designed with a microprocessor-based control system, it provides effective yet gentle treatment for delicate items. This unit is equipped with 30 standard washing programs, ensuring consistent and validated cleaning performance. Our Glassware Washer is ideal for cleaning laboratory glassware in pharmaceutical, research, clinical, and industrial lab environments.


Chamber Volume 158 L
Drying Method Box Drying
Cleaning Basket Layer One layer
Standard Program 30
Self-defined Program 120
Pump Circulation 0 to 400 L/min
Air Heating Power 0.5 kW
Screen Size 8.8 inch
Intelligent Switch Door Yes
Three-level Permissions Yes
Pipeline Pressure Monitoring Yes
Power 220 V, 5kW
Inner Dimension (L×W×H) 574 × 575 × 507 mm
Outer Dimension (L×W×H) 639 × 779 × 781 mm
Net Weight 150 kg
  • Customizable wash programs
  • Variable speed pump
  • Safety protection system
  • Box Drying
  • Low noise operation

Glassware Washer ADGW-501 is ideal for reliable glassware cleaning in scientific and industrial laboratories. It is also used in food, environmental, and chemical testing labs where thorough decontamination is essential.

Accessory NameQuantity
Upper Module Cleaning Basket (without spray arm)1 Pc
Upper Module Cleaning Basket (with spray arm)1 Pc
Lower Module Cleaning Basket (without spray arm)1 Pc
Spray Basket 8 for 250 to 2000ml Bottles & Flasks1 Pc
Spray Basket 21 for 50 to 250 ml Bottles & Flasks1 Pc
Spray Basket 50 for 10 to 100 ml Bottles & Flasks1 Pc
Spray Basket 66 for 10 to 50 ml Bottles & Flasks1 Pc
Spray Basket 25 for 500 ml Bottles & Flasks1 Pc
Spray Basket 20 for 1000 ml Bottles & Flasks1 Pc
Spray Basket 21 for 50 to 250 ml Flasks1 Pc
Spray Basket 32 for 50 to 250 ml Flasks1 Pc
Spray Basket 66 for 10 to 50 ml Flasks1 Pc
Spray Basket 50 for 10 to 100 ml Flasks1 Pc
Spray Basket 66 for 10 to 20 ml Test Tubes1 Pc
Spray Basket 66 for 10 to 50 ml Pipette1 Pc
Spray Bottle Module Basket 102 for Chromatographic Injection Bottles1 Pc
Spray Bottle Module Basket 102 for Chromatographic Injection Bottles1 Pc
Spray Bottle Module Basket 102 for Test Tubes & Centrifuge Tubes1 Pc
Spray Bottle Module Basket 102 for Pipettes & Graduated Pipettes1 Pc
Hybrid Module 102 for 78 Injection Bottles & 24 Pipettes1 Pc
Hybrid Module 102 for Injection Bottles & Pipettes (0.1 to 50ml)1 Pc
Hybrid Module 102 for 54 Injection Bottles & 48 Pipettes (0.1 to 50ml)1 Pc
Hybrid Module 102 for 54 Injection Bottles & 48 Test Tubes (0.1 to 50ml)1 Pc
Hybrid Module 102 for 78 Test Tubes & 24 Pipettes (0.1 to 50ml)1 Pc
Hybrid Module 102 for 54 Test Tubes & 48 Pipettes (0.1 to 50ml)1 Pc
Hybrid Module 48 for 24 Pipettes & 24 Volumetric Flasks (0.1 to 100ml)1 Pc
Hybrid Module 48 for 24 Injection Bottles & 24 Volumetric Flasks (0.1 to 100ml)1 Pc
Hybrid Module 74 for 50 injection bottles & 24 Volumetric Flasks (2 to 100ml)1 Pc
Hybrid Module 74 for 50 Pipettes & 24 Volumetric Flasks (2 to 100ml)1 Pc
1/2 Cleaning Frame Module for Jars, Glass Rods & Bottle Caps (10 to 2000ml)1 Pc
1/4 Fan-Shaped Cleaning Module for Test Tubes (10 to 20ml)1 Pc
1/4 Fan-Shaped Cleaning Module for Test Tubes & Centrifuge Tubes (10 to 20ml)1 Pc
Cleaning Frame Module for jars (10 to 2000ml)1 Pc
1/2 Cleaning Frame Module for 30 Petri dishes (60 to 150 ml)1 Pc
