Shaking Incubator ADSI-505 operates across a wide temperature range of 5℃ to 60℃. The MCU controller and advanced software enable low-noise operation. It is designed with over-thermal protection and a safety mechanism that operates when the lid is opened. This unit features an innovative balancing system that ensures stable performance even at high speeds. Our Shaking Incubator is ideal for cell and tissue culture, fermentation, hybridization, and biochemical reactions.


Temperature Control Range RT +5℃ to 60℃
Temperature Set Range 0℃ to 60℃
Temperature Precision ≤ ±0.3℃ at 37℃
Temperature Display Accuracy 0.1℃
Temperature Uniformity ≤ ±0.5℃ at 37℃
Amplitude 20 mm
Speed Range 50 to 300 rpm
Platform Dimension 420×420 mm
Maximum Height of Vessel 365 mm
Maximum Load 10 kg
Timer 1m to 99h /infinite
Power Consumption 650 W
Power Supply AC100 to 120V/ AC210 to 240V
Dimension (W×D×H) 525×770×535 mm
Net Weight 45 kg
  • Bright and vivid TFT screen
  • Integrated shaking and incubation
  • Durable design with compact dimensions
  • Flexible platform options for various labware
  • Brushless motor paired with high accuracy bearings

Our Shaking Incubator ADSI-505 is an ideal solution for a wide range of applications including cell and tissue culture, fermentation, hybridization, and biochemical reactions. It is widely used in medical, biological, pharmaceutical, food safety, and environmental research.

Accessory

Dimension

Flask type

and Capacity

Quantity

Flat type platform

420×420 mm

-

1 Pc

Universal platform with springs

410×410×80 mm

-

1 Pc

Platform with clamps 01

420×420 mm

50 ml×49

1 Pc

Platform with clamps 02

420×420 mm

100 ml×36 or 250 ml×16

1 Pc

Platform with clamps 03

420×420 mm

500 ml×9 or 1000 ml×5 or 2000× ml×4

1 Pc

Platform with adhesive mats

420×420 mm

50 ml×64 or 100 ml×36 or 250 ml×16 or 500 ml×9 or 1L×9 or 2L×4 or 3L×4

9 Pcs

Adhesive mat

420×420 mm

-

1 Pc

Shaking Incubator ADSI-505 |  Amplitude 20 mm |  Speed Range 50 to 300 rpm
Shaking Incubator ADSI-505 |  Bright and vivid TFT screen | Integrated shaking and incubation

Frequently Asked Questions of Shaking Incubator ADSI-505

1. How does the Shaking Incubator ensure stability during high-speed operation?

This Shaking Incubator is equipped with a unique balance system that guarantees stable and smooth performance even at high speeds. This design minimizes vibrations and enhances operational safety, ensuring consistent and reliable results throughout your experiments.

2. Does the Shaking Incubator support both oscillation and incubation functions?

Yes, our Shaking Incubator provides integrated oscillation and precise incubation (heating) capabilities. This combination enables controlled shaking along with accurate temperature regulation, ideal for applications such as cell culture, fermentation, and biochemical reactions.

3. What is the maximum vessel height supported by the Shaking Incubator?

This Shaking Incubator accommodates vessels up to a maximum height of 365 mm, allowing for a wide variety of lab containers to be used comfortably within the chamber. This generous clearance ensures compatibility with most standard beakers, flasks, and other labware. It also provides flexibility for different experimental setups.

4. Are optional platforms available for the Shaking Incubator?

Yes, our Shaking Incubator includes optional platforms designed to accommodate a variety of container types and experimental requirements. These interchangeable platforms provide flexibility, enabling customization for different flask sizes, tubes, or plates. This adaptability makes the incubator suitable for diverse laboratory applications.

5. What is the maximum load capacity of the Shaking Incubator?

This Shaking Incubator is engineered to handle a maximum load of 10 kg. Adhering to this limit ensures safe operation and optimal performance. To maintain equipment longevity and prevent damage, always distribute the load evenly across the platform for balanced shaking and reliable results.

6. What is a Shaking Incubator?

A Shaking Incubator is a laboratory device that combines temperature-controlled incubation with orbital shaking. It's commonly used for growing cultures of bacteria, yeast, and other microorganisms that require aeration. It ensures uniform mixing and optimal oxygen transfer, which are critical for efficient microbial growth.

7. How does a Shaking Incubator differ from a regular incubator?

A regular incubator maintains a stable temperature, while a Shaking Incubator also provides continuous shaking to ensure proper mixing and aeration, which is essential for growing aerobic organisms. The shaking action helps prevent sedimentation of cells and promotes even nutrient distribution. This makes shaking incubators ideal for applications like cell culture, fermentation, and protein expression studies.

8. What are the maintenance requirements in Shaking Incubator?

Regular maintenance of a Shaking Incubator includes cleaning the chamber to prevent contamination and ensure optimal hygiene. It's important to lubricate moving parts as recommended by the manufacturer to maintain smooth operation. Periodic calibration of temperature and shaking speed controls ensures accuracy and reliability. Users should routinely check for unusual vibrations, noises, or signs of wear to prevent potential malfunctions.
