Pulse Multi-Tube Vortex Mixer ADPMV-501 offers high-speed mixing from 100 to 2500 rpm with a 4mm shaking orbit for consistent results. It can mix up to 50 samples at a time. It is designed for quiet operation to reduce noise during operations. Our mixer features a real-time LED display that provides clear and accurate readings for easy speed and time monitoring.
| Speed | 100 to 2500 rpm |
| Amplitude | 4mm horizontal orbital shaking |
| Time Set | 1min to 99h59min |
| Max Load | 5.5kg |
| Mode | Pulse/Touch/timer/continuous |
| Input Power | 70W |
| Dimension | 515×385×470 mm |
| Weight | 20 kg |
Pulse multi-tube vortex mixer ADPMV-501 is used in various research and industrial labs to mix multiple samples. It is widely used in laboratories across fields such as biotechnology, pharmaceutical, chemical, analytical, clinical, diagnostic, and environmental science.
50Hole*￠9 suitable for test tube outer diameter 9 to 13mm
| Speed Range: | Touch: 0 to 3000 rpm <br/> Run: 200 to 3000 rpm |
| Operating Mode: | Touch/run |
| Control Mode: | Knob |
| Shaking Volume: | 80 ML |
| Operating Environment: | 5 to 40℃ |
| Shaking Speed: | 3000 RPM |
| Speed: | 0 to 2800 rpm |
| Orbital Diameter: | 3.6 mm |
| Operation: | Touch / Continuous |
| Speed Range: | Touch: 0 to 3000 rpm <br/> Run: 100 to 3000 rpm |
| Operating Mode: | Touch/run |
| Control Mode: | Digital display & button |
| Speed Range: | 200 to 3000 ±15 rpm |
| Shaking Mode: | Orbital |
| Motor/Drive Mode: | DC24V Permanent magnet brushless motor/direct drive |
| Speed Range: | 0 to 2800rpm |
| Shaking Mode: | Orbital |
| Motor Type: | DC motor |
| Speed Range: | 500 to 2500 rpm |
| Speed Control Accuracy: | ±1 rpm |
| Amplitude: | 3.6 mm |
| Speed Range: | 500 to 3000rpm |
| Amplitude: | 4mm horizontal swing |
| Maximum Load: | 4.5kg |
| Speed: | 15 to 3000 rpm |
| RPM Increment: | 10 rpm |
| Horizontal Gyration Amplitude: | 4 mm |
