| Capacity | 480 L |
| Temperature Range | -40 to -86°C |
| Cooling Performance | -80 °C |
| Cabinet Type Chest | Chest |
| Cooling Type Direct cooling | Direct cooling |
| Defrost Mode Manual | Manual |
| Refrigerant | R290/R170 |
| Display | 7" Touch screen with USB port |
| Interior Material | Stainess steel |
| Exterior Material | Galvanized steel powder coating |
| Insulation Material | PUF+VIP |
| High and Low Temperature Alarm | Yes |
| Hot Condenser | Yes |
| High Ambient Temp | Yes |
| Sensor Failure Alarm | Yes |
| Alarm Mode | Sound and light alarm, remote alarm terminal |
| Thickness of Cabinet Foamed Layer | 90 mm |
| Inner Door Number | 2 |
| Capacity for 2-inch boxes | 360 |
| Container Loading | 13/26 (20'/40') |
| Thickness of Door | 80 mm |
| Door Locking Device | Yes |
| Handle | Yes |
| Pressure Balance Hole | Yes |
| Caster | Yes |
| Test Hole | Yes |
| Climate Class | No |
| Temperature Recorder | Optional |
| Racks & Boxes | Optional |
| Energy consumption | 12.5 KW.H/24H |
| Power Supply | 220/50 V/Hz |
| Power Consumption | 800 W |
| Interior Dimensions (W×D×H) | 1310 x 600 x 600 mm |
| Exterior Dimensions (W×D×H) | 1965 x 860 x 900 mm |
| Packing Dimensions (W×D×H) | 2040 x 920 x 1060 mm |
| Net Weight | 242 kg |
| Gross Weight | 278 kg |
This -80°C Ultra Low Vertical Freezer ADFU-502 is employed in hospitals, research facilities, biorepositories, and industrial environments for the long-term preservation of delicate biological materials, including cells, tissues, and viral specimens.
1. What safety features are included in the -86°C Ultra Low Vertical Freezer ADFU-502?
The -86°C Ultra Low Vertical Freezer ADFU-502 includes buzzer alarms, flashing indicators, and door lock systems to prevent unauthorized access and alert users during faults. Temperature deviation alarms and power failure notifications are built-in for added reliability. These safety systems help protect valuable research and clinical materials.
2. What kind of compressor is used in this -86°C Ultra Low Vertical Freezer ADFU-502?
-86°C Ultra Low Vertical Freezer ADFU-502 uses a highly efficient SECOP compressor, designed specifically for ultra-low temperature applications. It offers rapid cooling, consistent performance, and reduced noise levels. This compressor ensures longevity and minimal energy consumption.
3. Can this -86°C Ultra Low Vertical Freezer ADFU-502 be used in GMP or clinical environments?
Yes, the -86°C Ultra Low Vertical Freezer ADFU-502 is suitable for Good Manufacturing Practice settings due to its stable performance and hygienic stainless-steel interior. It supports traceability, temperature logging, and secure storage of regulated materials. Its compliance with medical-grade standards ensures reliability in clinical use.
4. Is the -86°C Ultra Low Vertical Freezer ADFU-502 energy-efficient?
Yes, it is designed with energy-efficient components, including high-performance insulation and a low power consumption refrigeration system. It uses eco-friendly refrigerants and optimized compressor operation to reduce energy usage while maintaining ultra-low temperatures. This makes it suitable for continuous operation in labs and medical facilities with minimal environmental impact.
5. How is temperature monitoring handled in the -86°C Ultra Low Vertical Freezer ADFU-502?
-86°C Ultra Low Vertical Freezer ADFU-502 features a precise microprocessor-based control system that continuously monitors internal temperatures. It displays real-time readings on a touchscreen interface, allowing easy access to temperature logs. Additionally, the unit includes alarm systems for temperature deviations, power failures, and door openings, ensuring secure storage of sensitive materials.
6. What are -86°C Ultra Low Vertical Freezers used for?
They are designed for preserving sensitive biological samples, pharmaceuticals, and research specimens under extreme cold environments in labs and clinics. These units are essential for storing biological samples that require consistent ultra-low temperatures. Their vertical design maximizes floor space while allowing organized compartmentalized storage. With stable temperature performance, they ensure sample integrity over extended durations.
7. How do -86°C Ultra Low Vertical Freezers differ from -86°C Ultra Low Temperature Freezers? -
-86°C Ultra Low Vertical Freezers are distinguished by their upright, space-saving design, allowing easier access and organized shelving for high-volume storage. While both types maintain the same temperature range, vertical units offer ergonomic advantages of stored samples compared to horizontal. Ultra Low Temperature Freezers, which are often preferred for higher thermal stability.
