| Capacity | 80 L |
| Temperature Range |
With illumination 10 to 65 °C Without illumination 5 to 65 °C |
| Humidity Range | 45 to 95 % RH |
| Illuminance | 0 to 18,000 LX |
| Temperature Stability | ±1 °C |
| Humidity Stability | ±3 % RH |
| Power Consumption | 600 W |
| Power Supply | AC 220 V 50 Hz or AC 110 V 60 Hz |
| Interior Dimensions (D×W×H) | 400 × 400 × 500 mm |
| Exterior Dimensions (D×W×H) | 620 × 670 × 1160 mm |
| Shipping Dimensions (D×W×H) | 670 × 740 × 1290 mm |
| Net Weight | 73 kg |
| Gross Weight | 83 kg |
Plant Growth Chamber ADPGC-506 is ideal in labs and agriculture for controlled plant growth, seed germination, and material testing with precise climate conditions.
1. What is the capacity and application of the Plant Growth Chamber ADPGC-506?
The Plant Growth Chamber ADPGC-506 has an 80-liter interior, ideal for conducting controlled experiments. It supports plant growth, seed germination, microbial preservation, and various environmental simulations. This system ensures uniform conditions for reliable data collection. Its compact size suits both laboratories and research facilities. The unit is engineered for precision and versatility.
2. How does the Plant Growth Chamber ADPGC-506 manage temperature and humidity?
Plant Growth Chamber ADPGC-506 features microcomputer-based temperature regulation with stability of ±1°C. It offers a humidity range of 45 to 95% RH, stabilized at ±3% RH. Steam humidification and auto water refill ensure consistent moisture levels. Its dual-phase thermal setting accommodates light and dark periods. The system creates optimal environments for diverse test requirements.
3. What are the illumination capabilities of the Plant Growth Chamber ADPGC-506?
The Plant Growth Chamber ADPGC-506 supports adjustable illumination ranging from 0 to 18,000 LX. This enables precise simulation of natural daylight for plant studies. Light intensity is easily modifiable to match specific research protocols. It allows clear differentiation between photoperiodic phases. The unit facilitates healthy growth conditions under controlled lighting.
4. What design and build features are included in the Plant Growth Chamber ADPGC-506?
Plant Growth Chamber ADPGC-506 is built with a steel body coated in durable electrostatic powder. It includes a double-layered glass door with a magnetic seal for insulation. Its compact structure accommodates both portability and performance. Uniform air circulation and balanced cooling-heating cycles enhance system efficiency. Compressor protection and intelligent defrost add long-term durability.
5. What control and connectivity options does the Plant Growth Chamber ADPGC-506 offer?
Plant Growth Chamber ADPGC-506 includes a 30-segment programmable system for fine-tuned environmental control. USB support, printer compatibility, and a 485-communication port enable data recording. It features SMS alerts for real-time updates and safety notifications. Power-off and instrument error protections ensure operational security. Multi-parameter adjustments offer comprehensive research flexibility.
6. What are Plant Growth Chambers?
Plant Growth Chambers are specialized enclosures designed to maintain controlled environmental conditions, including temperature, humidity, and lighting. They are used for conducting experiments and research on plant growth, seed germination, and microbial cultures. These units ensure consistent conditions for reproducible results in scientific studies.
7. Where are Plant Growth Chambers applied in industry?
In industrial settings, Plant Growth Chambers are used for seed quality testing, crop improvement trials, and pharmaceutical plant-based product development. They support quality inspection for materials like wood, textiles, and building components under controlled environmental simulations. Such applications help improve product standards and agricultural outputs.
