| Main Chamber Dimension (L×B×H) | 600 × 450 × 450mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| H₂O and O₂ Index | 200 to 300PPM |
| Side Door Dimension (L×B) | 240 × 280mm |
| Window Material Thickness | 12mm tempered glass |
| Ball Valve | Stainless Steel balloon valve with integrated water nozzles for air, water entry |
| Light Source | LED light |
| Power Socket | Multi hole power sockets |
| Reserved Interface | KF reserved interface |
| Packaging dimensions | 770 x 650 x 670 mm |
| Gross Weight | 70 kg |
Stainless Steel Glove Box ADSSG-501 provides a sealed environment for safely handling chemicals and samples. It is commonly used in laboratories, research facilities, and industrial quality control.
Nitrile Gloves
1. How is the chamber vacuum controlled in Stainless Steel Glove Box ADSSG-501?
The Stainless Steel Glove Box ADSSG-501 vacuum system, with stainless steel ball valves, efficiently evacuates air to maintain low pressure. This ensures minimal moisture and oxygen, creating a stable, contamination-free environment for handling sensitive chemicals safely.
2. How are the gloves and ports maintained in Stainless Steel Glove Box ADSSG-501?
Stainless Steel Glove Box ADSSG-501 uses industrial-grade latex gloves with sealed ports, which are durable and easy to clean. Regular inspection and maintenance prevent contamination and ensure airtight operation, extending glove life.
3. Can the Stainless Steel Glove Box ADSSG-501 handle water-sensitive reactions?
Yes, Stainless Steel Glove Box ADSSG-501maintains H?O levels at 200–300?PPM using ball valves and a vacuum system, allowing safe handling of water-sensitive chemicals and reactions without contamination.
4. How easy is Stainless Steel Glove Box ADSSG-501 to monitor experiments inside?
Stainless Steel Glove Box ADSSG-501 features tempered glass panels and LED lighting for full visibility, enabling safe, accurate observation and manipulation of samples without disturbing the controlled low-oxygen, low-moisture environment.
5. How is the side access door in Stainless Steel Glove Box ADSSG-501 used?
The side door in Stainless Steel Glove Box ADSSG-501 allows safe insertion and removal of samples and small instruments without compromising the controlled atmosphere, maintaining low moisture and oxygen levels inside the main chamber.
6. Why is stainless steel used in glove boxes?
Stainless steel is used in glove boxes because it provides excellent durability, corrosion resistance, and long-term reliability. Its strong structure withstands demanding laboratory and industrial conditions, ensuring safe, stable, and contamination-free operation for sensitive applications.
7. How do Stainless Steel Glove Boxes improve lab safety?
By providing a fully sealed and controlled environment, stainless steel glove boxes protect users from hazardous materials and prevent contamination of samples, ensuring safe handling and maintaining the integrity of experiments in laboratories and industrial settings.
8. How does stainless steel enhance the lifespan of glove boxes?
Stainless steel construction provides exceptional strength and resistance to corrosion, chemicals, and wear. This ensures that glove boxes maintain their structural integrity and controlled environment for many years, even under heavy laboratory or industrial use.
| Main Chamber Dimension (L×B×H) | 800 × 650 × 680mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H) | 600 × 450 × 450mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H) | 1120 × 750 × 900mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H) | 800 × 650 × 680mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H): | 1000 × 750 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 800 × 550 × 600 mm |
| Antechamber Dimension (L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 500 × 500 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 700 × 450 × 550 mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1000 × 750 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 700 × 450 × 550 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 800 × 550 × 600mm |
| Material Thickness: | 6mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 500 × 500mm |
| Material Thickness: | 6mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1200 × 800 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 300 × 400 × 500mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1200 × 800 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 600 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 600 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Glove Box Type: | Stainless Steel Glove Box with H₂O & O₂ Purification System |
| Water Concentration: | <1 ppm at 20°C, 1 atm |
| Oxygen Concentration: | <1 ppm at 20°C, 1 atm |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Material: | Stainless steel, 3mm thickness |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
