| Main Chamber Dimension (L×B×H) | 800 × 650 × 680mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| H₂O and O₂ Index | 200 to 300PPM |
| Antechamber (Φ×L) | 280 × 280 mm |
| Side Door Dimension (L×B) | 330 × 380mm |
| Window Material Thickness | 12mm tempered glass |
| Ball Valve | Stainless Steel balloon valve with integrated water nozzles for air, water entry |
| Light Source | LED light |
| Power Socket | Multi hole power sockets |
| Reserved Interface | KF reserved interface |
| Power Supply | 220V, 50Hz / 60Hz |
Stainless Steel Glove Box ADSSG-505 is used in chemical, biotechnology, and quality control laboratories. It supports precise and secure handling of delicate samples in a stable, contamination-free environment.
1. How does Stainless Steel Glove Box ADSSG-505 maintain a controlled environment?
The Stainless Steel Glove Box ADSSG-505 maintains a safe, contamination-free environment with a -0.1 MPa vacuum and controlled low oxygen and moisture levels, ensuring precise handling of sensitive samples in research, pharmaceutical, and industrial applications.
2. Can lab instruments be connected inside the Stainless Steel Glove Box ADSSG-505?
Yes, the Stainless Steel Glove Box ADSSG-505 is equipped with multi-hole power sockets and a KF reserved interface, allowing flexible and convenient connection of various laboratory instruments for efficient and safe operations.
3. How are samples transferred safely inside Stainless Steel Glove Box ADSSG-505?
The Stainless Steel Glove Box ADSSG-505 features an antechamber that allows smooth and contamination-free transfer of samples between the main chamber and the outside environment, ensuring safe handling of sensitive materials during laboratory and industrial operations.
4. How durable is the Stainless Steel Glove Box ADSSG-505?
The Stainless Steel Glove Box ADSSG-505 is made of 304/316 stainless steel, offering excellent chemical resistance and long-term durability, making it ideal for demanding laboratory, pharmaceutical, and industrial applications requiring reliable performance.
5. Does Stainless Steel Glove Box ADSSG-505 support easy access for operators?
Yes, Stainless Steel Glove Box ADSSG-505 includes a side door and ergonomic design features to provide comfortable, safe, and efficient handling of samples, allowing operators to work effectively while minimizing the risk of contamination or strain.
6. Why is stainless steel used in glove boxes?
Stainless steel is used in glove boxes because it provides excellent durability, corrosion resistance, and long-term reliability. Its strong structure withstands demanding laboratory and industrial conditions, ensuring safe, stable, and contamination-free operation for sensitive applications.
7. How do Stainless Steel Glove Boxes improve lab safety?
By providing a fully sealed and controlled environment, stainless steel glove boxes protect users from hazardous materials and prevent contamination of samples, ensuring safe handling and maintaining the integrity of experiments in laboratories and industrial settings.
8. How does stainless steel enhance the lifespan of glove boxes?
Stainless steel construction provides exceptional strength and resistance to corrosion, chemicals, and wear. This ensures that glove boxes maintain their structural integrity and controlled environment for many years, even under heavy laboratory or industrial use.
| Main Chamber Dimension (L×B×H) | 800 × 650 × 680mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Material | Stainless steel |
| Air Lock Size | 200 mm dia. x 260 mm length |
| Main Chamber Size | 550 mm (W) x 440 mm (D) x 410 mm (H) |
| Main Chamber Dimension (L×B×H) | 600 × 450 × 450mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H) | 1120 × 750 × 900mm |
| Thickness | 3mm |
| Vacuum Degree | -0.1mpa |
| Main Chamber Dimension (L×B×H): | 1200 × 800 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 600 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 700 × 450 × 550 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1200 × 800 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 500 × 500mm |
| Material Thickness: | 6mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 800 × 550 × 600 mm |
| Antechamber Dimension (L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 300 × 400 × 500mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 700 × 450 × 550 mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1000 × 750 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 1000 × 750 × 700 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 600 × 700mm |
| Material Thickness: | 6 mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 900 × 500 × 500 mm |
| Antechamber Dimension(L×B×H): | 260 × 260 × 260mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Main Chamber Dimension (L×B×H): | 800 × 550 × 600mm |
| Material Thickness: | 6mm |
| H₂O and O₂ Content: | 200 to 300 PPM |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Material: | Stainless steel, 3mm thickness |
| Working Gas: | Nitrogen, argon (gas purity 99.999%) |
| H₂O and O₂ Index: | Less than 1PPM |
| Circulating Capacity: | Integrated fan flow rate of 90m³/h |
