High-Speed Refrigerated Centrifuge ADHSC-519
High-Speed Refrigerated Centrifuge ADHSC-519
High-Speed Refrigerated Centrifuge ADHSC-519
High-Speed Refrigerated Centrifuge ADHSC-519
High-Speed Refrigerated Centrifuge ADHSC-519

High-Speed Refrigerated Centrifuge ADHSC-519

High-Speed Refrigerated Centrifuge ADHSC-519 operates at a speed of 15000 rpm, providing consistent sample separation. The centrifuge supports various rotors for microplates, tubes, bottles, and swing-buckets. This unit has a touchscreen interface for easy control of speed, temperature, and time. It offers programmable protocols with memory storage for frequently used centrifugation routines. Our High Speed Refrigerated Centrifuge is used in biochemistry, pharmaceuticals and research labs for rapid separation of small particles.


Maximum Speed 15,000 rpm
Maximum RCF 21,630 × g
Maximum Capacity 12 × 5 ml
Temperature Range -10°C to +40°C
Temperature Accuracy ±1°C
Speed Accuracy ±10 rpm
Time Setting 1s to 99h 59m 59s
Noise ≤56 dB(A)
Power Consumption 400 W
Dimension 510 × 300 x 280 mm
Weight 29 kg
Gross Weight 35 kg
  • Digital display
  • High-speed performance
  • User-friendly interface
  • Quiet operation
  • Advanced refrigeration system

Our High Speed Refrigerated Centrifuge ADHSC-519 is used in clinical diagnostics, molecular biology, and research laboratories for rapid and temperature-controlled separation of biological samples.

Rotor Type

Capacity

Max Speed

Max RCF

Tube size

Fixed angle rotor 01

24x1.5/2.2ml

15000rpm

21633×g

Φ11x42mm

Fixed angle rotor 02

4x0.2ml PCR strip

15000rpm

19620×g

-

Fixed angle rotor 03

12x5ml

15000rpm

Φ14x54mm

Φ14x54mm

High-Speed Refrigerated Centrifuge ADHSC-519|Maximum RCF:21,630 × g|Temperature Range:-10°C to +40°C
High-Speed Refrigerated Centrifuge ADHSC-519|Digital display|High-speed performance

Frequently Asked Questions of High-Speed Refrigerated Centrifuge ADHSC-519

1. What kind of rotors and accessories are compatible with High Speed Refrigerated Centrifuge ADHSC-519?

The High Speed Refrigerated Centrifuge ADHSC-519 supports a wide range of rotors, including fixed-angle and swing-out rotors, making it compatible with tubes, bottles, microplates, and PCR strips. This flexibility allows it to be used across multiple disciplines such as biotechnology, clinical diagnostics, and pharmaceuticals. Rotors are designed for easy loading and unloading, and many are autoclavable for sterilization. Quick-change rotor systems reduce downtime between procedures.

2. What types of samples can be processed using the High Speed Refrigerated Centrifuge ADHSC-519?

The High Speed Refrigerated Centrifuge ADHSC-519 is suitable for processing a wide variety of biological, chemical, and clinical samples including blood, plasma, serum, DNA/RNA, proteins, cell lysates, and microorganisms. Its high-speed capability and precise temperature control make it ideal for sensitive molecular biology procedures. It’s commonly used in applications such as pelletizing cells, isolating nucleic acids, separating lipoproteins, and purifying viruses. The adaptable rotor system allows for handling of tubes of different sizes and types.

3. How does the High Speed Refrigerated Centrifuge ADHSC-519 ensure temperature stability during operation?

The High Speed Refrigerated Centrifuge ADHSC-519 uses a high-efficiency refrigeration system that actively monitors and adjusts the chamber temperature throughout the spin cycle. This ensures that the internal environment remains within the set temperature range, even during high-speed runs that generate heat. The system automatically compensates for thermal buildup, protecting sample integrity. Pre-cooling functionality allows the chamber to reach the desired temperature before loading samples.

4. What safety features are included in the High Speed Refrigerated Centrifuge ADHSC-519?

The High Speed Refrigerated Centrifuge ADHSC-519 is designed with multiple built-in safety features including lid interlock, imbalance detection, and over-speed protection. The lid remains locked during operation and only opens once the rotor has stopped completely. Imbalance detection prevents damage by automatically stopping the centrifuge if uneven loads are detected. Over-speed protection ensures the rotor does not exceed safe operational limits.

5. Is the High Speed Refrigerated Centrifuge ADHSC-519 easy to operate and program?

Yes, the High Speed Refrigerated Centrifuge ADHSC-519 features a user-friendly touchscreen interface that allows intuitive control over all parameters such as speed, time, temperature, and acceleration/deceleration rates. Users can create and save multiple programs for repeated runs, saving time and improving consistency. Real-time displays show operating status and remaining run time. Its programmable functions reduce manual errors and increase reproducibility. The interface is designed to be accessible even for first-time users.

6. What is a High Speed Refrigerated Centrifuge?

A High Speed Refrigerated Centrifuge is a laboratory instrument that combines high rotational speeds with temperature control to efficiently separate biological samples while preserving their integrity. It is essential for processing heat-sensitive samples by preventing thermal degradation during centrifugation. These centrifuges are widely used in molecular biology, clinical diagnostics, and biochemistry labs.

7. Why is refrigeration important in centrifugation?

Refrigeration helps maintain low temperatures during centrifugation, preventing heat buildup that can degrade temperature-sensitive samples like proteins, enzymes, and nucleic acids. It also minimizes enzymatic activity and preserves the biological function and structure of delicate molecules. This ensures accurate and reliable experimental results.

8. Can the High Speed Refrigerated Centrifuge maintain temperature during the entire run?

Yes, the High Speed Refrigerated Centrifuge system continuously cools the rotor chamber to maintain the set temperature throughout the centrifugation process. This ensures that sensitive samples remain stable and protected from heat-induced damage. Consistent temperature control is critical for reproducible and accurate experimental results.
